Vizaar Invizx98 Full HD pan-tilt camera
The German Vizaar has been providing high-quality inspection systems since 1997. Thanks to high investments in innovation, they are now at the world top. Inspecting turbine engines, gas engines, diesel engines, pipes in the food and pharma. Vizaars video borescopes are used for inspecting deviations in welds to use in customs activities. The applications are countless.
VIZAAR INVIZx98 digital pan-tilt-zoom camera
The INVIZx98 by viZaar sets a new benchmark in digital pan-tilt-zoom inspection technology. Delivering true Full HD resolution (1920 × 1080), it is engineered for high-precision visual inspections of large components where powerful illumination, seamless 360° visibility, and high-performance zoom are essential. With its compact Ø 98 mm design, the INVIZx98 enables high-resolution non-destructive testing (NDT) even in confined or hard-to-access areas.
Housed in Grade 5 titanium—a corrosion-resistant material widely used in aerospace applications—the INVIZx98 combines exceptional durability with a remarkably low weight. At just 1,900 grams, it is ideally suited for demanding industrial environments where precision, robustness, and minimal load are critical.
For applications requiring even lower weight and reduced surface contamination, the INVIZx98 is also available in a hard-anodized aluminium version (INVIZx98 Al). This lightweight alternative delivers the same outstanding inspection performance while offering maximum flexibility for sensitive inspection environments.
INVIZx98 – Key Features at a Glance
Corrosion-resistant housing in Grade 5 titanium or hard-anodized aluminium, featuring a compact Ø 98 mm design
Smooth, continuous 360° rotation with ±165° tilt and fast, precise positioning
Uncompressed Full HD+ imaging for lossless image quality, combined with optical 10× zoom and AI-ready output
Lightweight construction at just 1,900 g for easy handling in demanding inspection environments
Dimmable wide-angle LED illumination delivering up to 2,000 lumens for optimal visibility
Up to 8 hours of continuous inspection time using a standard professional-grade battery
Wide operating temperature range from −25 °C to +48 °C, extendable up to +75 °C
Superior Image Quality
Full HD Without Compromise
Experience a new level of inspection precision with the INVIZx98 pan-tilt camera. Featuring uncompressed Full HD resolution (1920 × 1080), the INVIZx98 delivers razor-sharp, lossless images without compromise. Its powerful 10× optical zoom reveals the smallest details from a safe distance, while a minimum focus distance of just 10 mm and outstanding low-light sensitivity of 0.125 Lux ensure exceptional image quality—even in dark, confined, or hard-to-access areas.
With a wide diagonal field of view of 68° in a 16:9 format (55° horizontal, 32° vertical), operators benefit from excellent situational awareness. One-touch white balance further simplifies accurate color reproduction across all inspection conditions.
Lossless data capture eliminates error-prone image scaling, enabling highly reliable detection of defects, corrosion, and critical irregularities. Elevate your non-destructive testing (NDT) with clarity and confidence only the INVIZx98 can deliver.
A New Era
The Path to Automation
Endless 360° rotation combined with a 330° tilt range (±165°) provides complete all-round visibility. Home and preset positions are reached in under two seconds, significantly reducing inspection time and improving responsiveness.
Powered by a high-performance 1/2.8″ CMOS Sony® IMX® sensor and precision 10× optical zoom, the INVIZx98 ensures full control over every inspection detail. Intelligent features such as position memory and customizable zero-point calibration enhance orientation inside vessels and support repeatable, automated inspection routines—streamlining workflows and maximizing efficiency in complex environments.
Broad Range of Applications
Unlimited Versatility
With a standard water resistance of up to 45 meters (4.5 bar), the INVIZx98 is perfectly suited for underwater and high-humidity environments. Its operating temperature range from –25°C to +48°C allows it to withstand demanding conditions, setting new standards across a wide range of inspection applications.
Large components that require intense illumination, 360° visibility, and powerful zoom benefit from its exceptional performance, just like tanks, reactors, and agitator vessels.
The INVIZx98 proves especially reliable in underwater operations, such as inspections of nuclear function groups, marine components, or other flooded environments, where absolute dependability is essential.
Innovative Control with the VUnit
The INVIZx98 is complemented by the cutting-edge VUnit documentation system, which offers an intuitive user interface designed for ease of use. Equipped with scroll wheels, joysticks, and direct-access buttons, it enables precise and efficient camera control during inspections.
With uncompromising Full HD+ resolution and an interface layout positioned outside the live inspection image, the VUnit ensures unobstructed visibility of every detail, allowing operators to focus fully on their inspection tasks.
Comprehensive Documentation and Data Management
Create seamless inspection reports with the integrated comment function and the display of technical data. The VUnit allows you to seamlessly evaluate and organize your recordings. With the HDMI output, you can easily present your results on an external monitor. The INVIZx98 in combination with the VUnit documentation unit offers you a powerful and future-proof full HD inspection system for the highest demands. Experience visual inspections on a new level – with the INVIZx98 from viZaar.
The INVIZx98 by viZaar is a cutting-edge Full HD pan-tilt-zoom camera that redefines remote visual inspection. Combining a compact form factor with advanced imaging and positioning technology, it delivers precise, high-detail inspections across a wide range of demanding applications.
Typical use cases include:
Inspection of large-volume assets requiring powerful illumination, full 360° visibility, and high-performance zoom, such as tanks, boilers, shafts, and internal structures
Detailed examination of agitator vessels and internal reactor components
Underwater inspections of nuclear system components, ship structures, and other submerged environments
Specialized inspection tasks in the pharmaceutical, chemical, and food processing industrie
