Opti-mize Optivision VX video borescope
The Opti-mize Optivision VX videoborescope delivers powerful inspection performance in a compact, user-friendly system. With full HD imaging, ultra-small probe options, and advanced 2D measurement modes, it provides unmatched clarity and precision for identifying defects, blockages, and hidden issues. Its 360° electric joystick control and versatile light options—white, UV, and IR—make it the perfect tool for industrial inspections, maintenance, security operations, and search-and-rescue tasks. Read more in the brochure
Description
The Opti-mize Optivision VX videoborescope delivers advanced 2D measurement capabilities, including point-to-point, point-to-line, point-to-surface, polyline, area, and more. It features an intuitive, user-friendly interface and an 8-function videoscope equipped with a 5-inch 1920×1080 full HD touchscreen.
Features
Available in multiple configurations, the system supports ultra-small-diameter probes (1.0 / 1.2 / 1.8 mm and 2.4 / 2.8 mm) with 500,000-pixel resolution, as well as larger 4 / 6 / 8 mm probes with 1080P HD imaging. Probe options include white light, ultraviolet, and infrared illumination. Probes larger than 2.0 mm offer side-view or dual-view HD, while the 6 mm and 8 mm dual-view probes support optical zoom and optional retrieval/salvage tools.
Applications
Ideal for detecting foreign objects, weld integrity, blockages, and defects in pipelines, containers, machinery, and equipment. It is also suitable for specialized applications such as counter-terrorism operations, search and rescue missions, and other inspection scenarios.
Specifications
High-resolution display
• 5-inch LCD touchscreen
• 1920×1080 resolution
• Interactive menu for easy, intuitive operation
Electric joystick
• Smooth, low-effort control
• 360° probe articulation for maximum efficiency
Multiple configurations
• Ultra-small diameter probes: 1.0 / 1.2 / 1.8 mm
• 2.4 / 2.8 mm probes with 500,000-pixel resolution
• 4 / 6 / 8 mm 1080P HD probes
• White light, ultraviolet, and infrared options
• Probes >2.0 mm with side-view or dual-view HD
• 6 / 8 mm dual-view probes with zoom function
• 6 / 8 mm dual-view probes with optional salvage tools
2D measurement
• Point-to-point
• Point-to-line
• Point-to-surface
• Polyline
• Area and additional measurement modes
Made to travel
The videoscope and its accessories fit neatly in a lightweight travel case.
